H81M-V3 specifications summary
Storage
Intel
®
H81 Express Chipset:
- 2 x Serial ATA 6.0 Gb/s connectors (gray)
- 2 x Serial ATA 3.0 Gb/s connectors (black)
- Supports Intel
®
Rapid Technology* and Intel
®
Smart Connect
Technology**
* Due to the limitation of Intel
®
H81 chipset, Intel Rapid
®
Start Technology can be
configured only from the BIOS Setup program.
** The functions will work depending on the CPU installed.
Audio
Realtek
®
ALC887 7.1-channel Audio CODEC
- Supports jack-detection, multi-streaming, front panel jack-retasking
• UseachassiswithHDaudiomoduleinthefrontpaneltosupporta7.1-channel
audio output.
LAN
Realtek 8111G PCIe Gigabit LAN controller
USB Intel
®
H81 Express Chipset
- ASUS USB 3.0 Boost support
- 2 x USB 3.0/2.0 ports at back panel
- 8 x USB2.0/1.1 ports (6 ports at midboard, 2 ports at back panel)
ASUS unique
features
ASUS 5X Protection
- ASUS motherboards safeguard your PC with 5X Protection: DIGI+VRM,
DRAM Fuse, ESD Guards, High-Quality 5K-Hour Solid Capacitors, and
Stainless Steel Back
ASUS Digital Power Design
- Digital Power Control: Digital Power Design for the CPU
- ASUS 4 Phase Power Design
- ASUS CPU power utility
ASUS DRAM Fuse
- Enhanced DRAM overcurrent protection and short circuit damage
prevention
ASUS ESD Guards
- Strong ESD protection for extended component lifespan
ASUS High-Quality 5K-Hour Solid Capacitors
- 2.5x Longer lifespan with excellent durability
ASUS Stainless Steel Back I/O
- 3x More durable corrosion-resistant coating
ASUS Exclusive Features
- ASUS EPU
- ASUS USB 3.0 Boost
- ASUS Disk Unlocker featuring 3TB+HDD support
- ASUS Ai Charger
- ASUS GPU Boost
- ASUS AI Suite 3
- ASUS Anti-Surge protection
(continued on the next page)
7
