2.5.16 CPU Core/Cache Voltage [Auto]

This item allows you to congure the amount of voltage fed to the CPU cores. Increase the

voltage when setting a high Core Frequency value. Conguration options: [Auto] [Manual

Mode] [Offset Mode]

The following item appears only when you set the CPU Core Voltage to [Manual Mode].

CPU Core Voltage Override [Auto]

Allows you to set the input voltage for the CPU by the external voltage regulator. Use the

<+> or <-> keys to adjust the value. The values range from 0.600V to 1.700V with a 0.005V

interval.

The following items appear only when you set the CPU Core Voltage to [Offset Mode].

Offset Mode Sign [+]

[+] To offset the voltage by a positive value.

[–] To offset the voltage by a negative value.

CPU Core Voltage Offset [Auto]

Use the <+> or <-> keys to adjust the value. The values range from -0.635V to +0.635V with

a 0.005V interval.

2.5.17 DRAM Voltage [Auto]

This item allows you to set the voltage for the DRAM. Use the <+> and <-> keys to adjust the

value. The values range from 1.000V to 1.800V with a 0.005 interval.

2.5.18 CPU System Agent Voltage [Auto]

This item allows you to set the voltage for the CPU System Agent. Use the <+> and <-> keys

to adjust the value. The values range from 0.700V to 1.685V with a 0.005V interval.

2.5.19 CPU Graphics Voltage Mode [Auto]

This item allows you to congure the mode of voltage fed to the CPU Graphics Voltage.

Manual mode allows user-dened values. Offset mode modies values by SVID.

Conguration options: [Auto] [Manual Mode] [Offset Mode]

The following item appears only when you set the CPU Graphics Voltage Mode to [Manual

Mode].

CPU Graphics Voltage Override [Auto]

This item allows you to congure the CPU Graphics Voltage Override. Use the <+> or <->

keys to adjust the value. The values range from 0.600V to 1.700V with a 0.005V interval.

2-24 Chapter 2: Getting started
