viii
H170M-E D3 specications summary
(continued on the next page)
ASUS unique
features
Gaming Scenario
Audio Features
- Audio that roars on the battleeld
Stream Support
- Compatible with the most fun gaming platform under Windows
®
system
Media Streamer
- Pipe music or movies from your PC to a smart TV
- Media Streamer app for portable smartphone/tablet, supporting iOS7 and
Android 4.0 system
ASUS Exclusive Features
- ASUS AI Charger
- ASUS AI Suite 3
- ASUS Anti Surge
EZ DIY
Push Notice
- Monitor your PC status with smart devices in real time
UEFI BIOS EZ Mode
- Featuring friendly graphics user interface
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 3
Q-Design
- ASUS Q-Slot
- ASUS Q-DIMM
ASUS quiet
thermal
solution
Quiet Thermal Design
- ASUS Fan Xpert 2+
- Stylish Fanless Design: PCH heatsink solution
Rear panel I/O
ports
1 x PS/2 keyboard port (purple)
1 x PS/2 mouse port (green)
1 x HDMI port
1 x DVI-D port
1 x RGB port
1 x LAN (RJ-45) port
4 x USB 3.0/2.0 ports (blue)
2 x USB 2.0/1.1 ports
3 x Audio jacks support 8-channel audio output*
* Use a chassis with HD audio module in the front panel to support a 8-channel audio
output.
