Asus h170m-e d3 [59/83] Pch core voltage auto

The following item appears only when you set the CPU Core Voltage Mode to [Offset

Mode].

Offset Mode Sign [+]

[+] To offset the voltage by a positive value.

[–] To offset the voltage by a negative value.

CPU Graphics Voltage Offset [Auto]

This item allows you to congure the CPU Graphics Voltage Offset. Use the <+> or <-> keys

to adjust the value. The values range from 0.001V to 0.635V with a 0.005V interval.

2.5.20 PCH Core Voltage [Auto]

This item allows you to set the PCH core voltage. Conguration options: [Auto] [1.00V]

[1.05V] [1.10V] [1.15V]

2.5.21 DRAM REF Voltage Control

DRAM CTRL REF Voltage [Auto]

Allows you to set the DRAM reference voltage on the control lines. You can use the <+> or

<-> keys to adjust the value. The values range from 0.39500V to 0.63000V with a 0.00500V

interval.

DRAM DATA REF Voltage on CHA [Auto]

Allows you to set the DRAM reference voltage on the data lines of channel A. You can use

the <+> or <-> keys to adjust the value. The values range from 0.39500V to 0.63000V with a

0.00500V interval.

DRAM DATA REF Voltage on CHB [Auto]

Allows you to set the DRAM reference voltage on the data lines of channel B. You can use

the <+> or <-> keys to adjust the value. The values range from 0.39500V to 0.63000V with a

0.00500V interval.

ASUS H170M-E D3 2-25
