Asus h170m-e d3 [9/83] H170m e d3 specifications summary
![Asus h170m-e d3 [9/83] H170m e d3 specifications summary](/views2/1162362/page9/bg9.png)
ix
H170M-E D3 specications summary
Internal
connectors
2 x USB 3.0 / 2.0 connector support additional 4 USB 3.0/ 2.0 ports (9-pin)
2 x USB 2.0 / 1.1 connectors support additional 4 USB 2.0/ 1.1 ports
1 x M.2 Socket 3 (for M Key, type 2242/2260/2280 devices)
4 x SATA 6.0 Gb/s connectors
1 x CPU fan connector (PWM mode only)
2 x Chassis fan connectors (4-pin) for both 3-pin (DC mode) and 4-pin (PWM
mode) coolers control
1 x Front panel audio connector (AAFP)
1 x TPM connector
1 x S/PDIF out header
1 x LPT header
1 x COM connector
1 x 24-pin EATX power connector
1 x 8-pin EATX 12V power connector
1 x System panel connector
1 x Clear CMOS header
BIOS features
128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI 3.0, WfM2.0, SM BIOS 3.0,
ACPI 5.0, Multi-language BIOS, ASUS EZ Flash 3, ASUS CrashFree BIOS 3,
F11 EZ Tuning Wizard, F6 Qfan Control, F3 My Favorites, Quick Note, Last
Modied Log, F12 PrintScreen function, and ASUS DRAM SPD (Serial Presence
Detect) memory information
Manageability
WfM 2.0, DMI 3.0, WOL by PME, PXE
Support DVD
Drivers
ASUS utilities
EZ Update
Anti-virus software (OEM version)
OS support
Windows
®
10 (64-bit),
Windows
®
8.1 (64-bit),
Windows
®
7 (32-bit / 64-bit)
* Please refer to ASUS website and download “Window
®
7 installation guide” and
“ASUS EZ installer” to install Windows
®
7.
Form factor
uATX form factor: 9.6 in. x 8.8 in. (24.4 cm x 22.4 cm)
Specications are subject to change without notice.
