2.6.8 Onboard Devices Conguration
HD Audio Controller [Enabled]
[Enabled] Enables the HD Audio Device.
[Disabled] Disables the HD Audio Device.
The following two items appear only when you set the HD Audio Controller item to
[Enabled].
Front Panel Type [HD Audio]
Allows you to set the front panel audio connector (AAFP) mode to legacy AC’97 or
high-denition audio depending on the audio standard that the front panel audio
module supports.
[HD Audio] Sets the front panel audio connector (AAFP) mode to high denition
audio.
[AC97] Sets the front panel audio connector (AAFP) mode to legacy AC’97
SPDIF Out Type [SPDIF]
[SPDIF] Sets to an SPDIF audio output.
[HDMI] Sets to an HDMI audio output.
Realtek LAN Controller [On]
[On] Enables the Realtek LAN controller.
[Off] Disables the controller.
Realtek PXE Option ROM [Off]
This item appears only when you set the previous item to [On] and allows you to enable or
disable the PXE OptionRom of the Realtek LAN controller. Conguration options: [On] [Off]
Charging USB devices in Power State S5 [Disabled]
[Enabled] Charges USB devices even when the system is in Power State S5. State
S5 is the soft-off mode or shutdown state where your computer has no
memory state and is not doing any computing tasks.
[Disabled] Disables this function.
Serial Port Conguration
The sub-items in this menu allow you to set the serial port conguration.
Serial Port [On]
Allows you to enable or disable the serial port (COM).Conguration options: [On] [Off]
Change Settings [IO=3F8h; IRQ=4]
This item appears only when you set the Serial Port to [On] and allows you to select
the Serial Port base address. Conguration options: [IO=3F8h; IRQ=4] [IO=2F8h;
IRQ=3] [IO=3E8h; IRQ=4] [IO=2E8h; IRQ=3]
Parallel Port Conguration
The sub-items in this menu allow you to set the parallel port conguration.
2-32 Chapter 2: Getting started
