Megaline Rack

5.3 Electrical input specifications

5.4 Output wave form

3 103 38 3 103 39 3 103 40 3 103 41

Nominal input voltage 230 V

Input voltage range from 184V to 264V with nom. load – from 100V to 264V with 50% of nom. load

Nominal input frequency 50 Hz or 60 Hz +/-2% (autosensing and/or as selected by operator)

Nominal input current 4,6A rms 8,9A rms 13,2A rms 17,7A rms

Maximum input current 5,75A rms 11,2A rms 16,6A rms 22,2A rms

Distortion of input current THD < 3%

Input power factor > 0,99 dal 20% of nominal load

In-rush current 100% of nominal current

Number of input phases Single phase

Line fuse 25 AFF

Battery charger directly

from mains

0,8 A rms

3 103 38 3 103 39 3 103 40 3 103 41

With mains operation Sine wave

With battery operation Sine wave

Type of operation

No break, on line UPS with passing neutral

and double conversion
