Printer Driver
Device Settings Sheet (W indows)
Many settings items on the printer properties sheets are controlled by Windows applications. However , the
Device Settings sheet is for conguring the printer , and it is an extension of the printer driver .
The following settings are available on the Device Settings sheet.
Setting Item Description
A About
Y ou can display version information for the printer driver .
Windows Software 383
