Canon imageprograf ipf605 [79/578] Main menu settings during printing
![Canon imageprograf ipf605 [79/578] Main menu settings during printing](/views2/1165621/page79/bg4f.png)
Control Panel
Main Menu Settings (During Printing)
Main menu items during printing are described in the following tables.
For instructions on menu operations, see “Main Menu Operations”. (→P .37)
For details on menu levels and values, see “Menu Structure”. (→P .41)
Setting Item
Description, Instructions
Head Cleaning Specify Printhead cleaning options. ( → P .480)
Choose Head Cleaning A if printing is faint, oddly colored, or contains foreign
substances.
Choose Head Cleaning B if no ink is printed at all, or if printing is not improved
by Head Cleaning A .
Fine Band Adj. Displayed during print jobs. For ne-tuning the feed amount.
Information Displays information about the printer and record of print jobs. ( → P .65)
Information
Setting Item Description, Instructions
Firm Displays the printer rmware version.
Boot Displays the version of the boot ROM.
V ersion
MIT Displays the version of the MIT database format.
Ext I/F Displays the name of interfaces compatible with
the expansion slot.
s/n Displays the printer ’ s serial number .
MAC Displays the MAC address.
System Info
IP Displays the printer ’ s IP address.
Error Log ########-#### Displays the most recent error messages (up to
two).
Document Name Displays the document name in the last print job.
User Name Displays the name of the user who sent the print
job.
Page Count Displays the number of pages in the print job.
Job Status Displays the results of the print job processed.
Print Start T ime Displays the time when the print job was started.
Print End T ime Displays the time when the print job was nished.
Print T ime Displays the time required to print the job.
Print Size Displays the paper size in the print job.
Media T ype Displays the paper type in the print job.
Interface Displays the interface used for the print job.
Job Log (Choose from
information
about the latest
three print jobs.)
Ink Consumed Displays the ink consumption.
Printer Parts 65
