Problems with the printing quality
Banding in different colors occurs
Cause Corrective Action
The roll is not loaded correctly in the Roll Feed Unit . Remove the roll and reload it.
( → P .1 14)
The paper feed amount is not adjusted correctly . Adjust the feed amount.
( → P .458)
Printing does not proceed smoothly because print
jobs are interrupted during transmission.
Exit other applications and cancel other print jobs.
In the printer menu, Print Length is specied in
Feed Priority .
T o adjust the feed amount, specify Band Joint in
Feed Priority in the printer menu.
( → P .458)
The Printhead is out of alignment. Adjust the Printhead alignment.
( → P .453)
Streaks may occur if you set the Print Quality too
low .
Choose a higher level of Print Quality in the
Advanced Settings of the printer driver and try
printing again.
( → P .193)
522 T roubleshooting
