Printer Specications
Basic Environmental Performance
Printer
Sleep mode 100-120 V : 5 W max.
(10 W max. when an IEEE 1394 (FireWire) expansion board is
installed.)
220-240 V : 6 W max.
(1 1 W max. when an IEEE 1394 (FireWire) expansion board is
installed.)
Power consumption
Of f 1 W max.
W eight 45 kg (99.2 lb)
Dimensions (W × D
× H)
997×670×344 mm (39.3×26.4×13.5 in)
Resource ef ciency
Recycling Recyclable plastic used for printer body
Structural components: No prohibited brominated ame
retardants used (PBB or PBDE)
T oxic substances
Body plastic: No heavy metals (Pb, Hg, Cr[Vl], or Cd) or
halogenated ame retardants used
Product safety
Operating noise Approx. 49 dB (A) max.
Packaging materials
Heavy metal content (Pb, Hg, Cr[Vl], and Cd) None (none in packaging)
80 Printer Parts
