99D-Link DIR-860L User Manual
Section 3 - Conguration
The Ping Test is used to send Ping packets to test if a
computer is connected to the Internet. Enter the IP address
that you wish to Ping and click Ping.
Enter the IPv6 address that you wish to Ping and click Ping.
The results of your ping attempts will be displayed here.
System Check
Ping Test:
IPv6 Ping Test:
Ping Results:
