Chapter 9 VLAN
MES3500 Series User’s Guide
102
9.9 VLAN MAC Learning
Use this screen to set the MAC address learning limit on per-port and per-VLAN basis. Click VLAN
MAC Learning in the VLAN Status screen to display the screen as shown next.
Mask-Bits Type the mask for the specified MAC address to determine which bits a packet’s MAC
address should match.
Enter “f” for each bit of the specified source MAC address that the traffic’s MAC address
should match. Enter “0” for the bit(s) of the matched traffic’s MAC address, which can
be of any hexadecimal character(s). For example, if you set the MAC address to
00:13:49:00:00:00 and the mask to ff:ff:ff:00:00:00, a packet with a MAC address of
00:13:49:12:34:56 matches this criteria.
VID Type an ID (from 1 to 4094) for the VLAN ID that is associated with the MAC-based
VLAN entry.
Priority Type a priority (0-7) for the MAC-based VLAN entry.The higher the numeric value you
assign, the higher the priority for this MAC-based VLAN entry.
Add Click Add to save the new MAC-based VLAN entry.
Cancel Click Cancel to clear the fields in the MAC-based VLAN entry.
Index This field displays the index number of the MAC-based VLAN entry.
Active This field shows whether the MAC-based VLAN is active or not.
Name This field displays the name of the MAC-based VLAN entry.
MAC Address This field displays the source MAC address that is bind to the MAC-based VLAN entry.
Mask-Bits This field shows the MAC mask in bit number format for this MAC-based VLAN.
VID This field displays the VLAN ID of the MAC-based VLAN entry.
Priority This field displays the priority level of the MAC-based VLAN entry.
Delete Click this to delete the MAC-based VLANs which you marked for deletion.
Cancel Click Cancel to clear the check boxes.
Table 23 Advanced Application > VLAN > VLAN Port Setting > MAC Based VLAN (continued)
LABEL DESCRIPTION
