Chapter 40 Access Control
MES3500 Series User’s Guide
306
voltage VoltageEventOn 1.3.6.1.4.1.890.1.5.8.68.27.2.1
1.3.6.1.4.1.890.1.5.8.57.27.2.1
1.3.6.1.4.1.890.1.5.8.80.27.2.1
This trap is sent when the voltage goes
above or below the normal operating range.
VoltageEventClear 1.3.6.1.4.1.890.1.5.8.68.27.2.2
1.3.6.1.4.1.890.1.5.8.57.27.2.2
1.3.6.1.4.1.890.1.5.8.80.27.2.2
This trap is sent when the voltage returns to
the normal operating range.
reset UncontrolledResetEventO
n
1.3.6.1.4.1.890.1.5.8.68.27.2.1
1.3.6.1.4.1.890.1.5.8.57.27.2.1
1.3.6.1.4.1.890.1.5.8.80.27.2.1
This trap is sent when the Switch
automatically resets.
ControlledResetEventOn 1.3.6.1.4.1.890.1.5.8.68.27.2.1
1.3.6.1.4.1.890.1.5.8.57.27.2.1
1.3.6.1.4.1.890.1.5.8.80.27.2.1
This trap is sent when the Switch resets by
an administrator through a management
interface.
RebootEvent 1.3.6.1.4.1.890.1.5.0.1 This trap is sent when the Switch reboots by
an administrator through a management
interface.
timesync RTCNotUpdatedEventOn 1.3.6.1.4.1.890.1.5.8.68.27.2.1
1.3.6.1.4.1.890.1.5.8.57.27.2.1
1.3.6.1.4.1.890.1.5.8.80.27.2.1
This trap is sent when the Switch fails to get
the time and date from a time server.
RTCNotUpdatedEventClea
r
1.3.6.1.4.1.890.1.5.8.68.27.2.2
1.3.6.1.4.1.890.1.5.8.57.27.2.2
1.3.6.1.4.1.890.1.5.8.80.27.2.2
This trap is sent when the Switch gets the
time and date from a time server.
intrusionlock IntrusionLockEventOn 1.3.6.1.4.1.890.1.5.8.68.27.2.1
1.3.6.1.4.1.890.1.5.8.57.27.2.1
1.3.6.1.4.1.890.1.5.8.80.27.2.1
This trap is sent when intrusion lock occurs
on a port.
loopguard LoopguardEventOn 1.3.6.1.4.1.890.1.5.8.68.27.2.2
1.3.6.1.4.1.890.1.5.8.57.27.2.2
1.3.6.1.4.1.890.1.5.8.80.27.2.2
This trap is sent when loopguard shuts down
a port.
errdisable errdisableDetectTrap 1.3.6.1.4.1.890.1.5.8.68.130.4.1
1.3.6.1.4.1.890.1.5.8.57.130.4.1
1.3.6.1.4.1.890.1.5.8.80.130.4.1
This trap is sent when an error is detected
on a port, such as a loop occurs or the rate
limit for specific control packets is
exceeded.
errdisableRecoveryTrap 1.3.6.1.4.1.890.1.5.8.68.130.4.2
1.3.6.1.4.1.890.1.5.8.57.130.4.2
1.3.6.1.4.1.890.1.5.8.80.130.4.2
This trap is sent when the Switch ceases the
action taken on a port, such as shutting
down the port or discarding packets on the
port, after the specified recovery interval.
Table 143 SNMP System Traps (continued)
OPTION OBJECT LABEL OBJECT ID DESCRIPTION
