▶HDMI Port

The High-Denition Multimedia Interface (HDMI) is an all-digital audio-video interface

that is capable of transmitting uncompressed streams. HDMI supports all types of TV

formats, including standard, enhanced, or high-denition video, plus multi-channel

digital audio on a single cable.

▶DisplayPort

DisplayPort is a digital display interface standard. This connector is used to connect a

monitor with DisplayPort inputs.

Important

This platform supports dual-display function.

HDMI+DisplayPort

Extend mode

(Extend the desktop to the second and third monitor)

◯

Clone mode

(Monitors have the same screen)

◯

▶Audio Ports

These connectors are used for audio devices. The color of the jack refers to the

function of the connector.

■ Blue-Line in: Used for connecting external audio outputting devices.

■ Green- Line out: Used as a connector for speakers or headphone.

■ Pink- Mic: Used as a connector for a microphone.

■ Black- RS-Out: Rear surround sound line out in 4/ 5.1/ 7.1 channel mode.

■ Orange- CS-Out: Center/ subwoofer line out in 5.1/ 7.1 channel mode.

■ Gray- SS-Out: Side surround sound line out in 7.1 channel mode.
