Chapter 1
Introduction
1-1 Overview
The SuperServer 6027R-TRF is a high-end server comprised of two main
subsystems: the SC825TQ-R740LP 2U server chassis and the X9DRi-F dual
processor serverboard. Please refer to our web site for information on operating
systems that have been certifi ed for use with the system (www.supermicro.com).
In addition to the serverboard and chassis, various hardware components have
been included with the SuperServer 6027R-TRF, as listed below:
• Two (2) 2U Passive CPU Heatsinks (SNK-P0048PS)
• One (1) Air shroud (MCP-310-29001-0N)
• Three (3) 80x80x38-mm Chassis Middle Fans (FAN-0126L4)
• One (1) 76-cm round 16-to-16-pin Ribbon FP Cable (CBL-0017L)
• SAS/SATA Accessories
One (1) SAS/SATA backplane (BPN-SAS-825TQ)
Two (2) 40-cm 8-to-8-pin ribbon cable w/tube for SGPIO (CBL-157L)
Four (4) 61-cm fl at SATA cables (CBL-0044L)
Two (2) 35-cm fl at SATA cables (CBL-0061L)
Eight (8) hot-swap 3.5" hard-disk drive trays (MCP-220-00075-0B)
• One (1) Rackmount kit (MCP-290-00053-0N)
Note: For your system to work properly, please follow the links below to download
all necessary drivers/utilities and the user’s manual for your server.
• Supermicro product manuals: http://www.supermicro.com/support/manuals/
• Product drivers and utilities: ftp://ftp.supermicro.com
• Product safety information:
http://super-dev/about/policies/safety_information.cfm
• If you have any questions, please contact our support team at:
support@supermicro.com
Chapter 1: Introduction
1-1
