5-14
SUPERSERVER 6027R-TRF USER'S MANUAL
X9DRi-F Quick Reference
Jumper Description Default Setting
JBT1 CMOS Clear (See Section 5-9)
JPB1 BMC Enabled Pins 1-2 (Enabled)
JPG1 VGA Enabled Pins 1-2 (Enabled)
JPL1 GLAN1/GLAN2 Enable Pins 1-2 (Enabled)
JPME1 Manufacture Mode Pins 1-2 (Normal)
JWD Watch Dog Timer Enable Pins 1-2 (Reset)
JWP1 Write-Protect Enable Pins 1-2 (Normal)
LED Description State Status
DM1 BMC Heartbeat LED Green BMC Normal
LE1 Standby PWR LED Green: On SB Power On
Connector Description
COM1/COM2 Backplane COM Port1/Front Accessible COM2 Header
FAN1~6, FAN A, FAN B CPU/System Fan Headers
I-SATA 0/1 Intel SB SATA 3.0 Connectors 0/1 (Color: White)
I-SATA 2~5 Intel SB SATA 2.0 Connectors 2~5 (Color: Black)
J22 (JPWR3) ATX 24-Pin Power Connector
JPWR1/2 12V 8-Pin Power Connectors
JD1 Speaker/Power LED Indicator
JF1 Front Panel Control Header
JIPMB1 4-pin External BMC I
2
C Header (for an IPMI Card)
JL1 Chassis Intrusion
JOH1 Overheat LED Indicator
JP3 BIOS Recovery
JPI
2
C1 Power Supply SMBbus I
2
C Header
JSTBY1 Standby Header
JTPM1 TPM (Trusted Platform Module)/Port 80
JWF1 SATA DOM (Disk on Module) Power Connector
Keyboard/Mouse PS2 Keyboard/Mouse (optional)
LAN1/LAN2 1G LAN Ethernet Ports 1/2
(IPMI) LAN IPMI_Dedicated LAN
T-SGPIO 1/2 Serial_Link General Purpose I/O Headers
BP USB 0/1, 2/3 Back Panel USB 0/1, 2/3
USB 4/5, USB 6, USB 8/9, USB 10/11 Front Panel Accessible USB Connections
VGA Backpanel VGA Port
