5-18
SUPERSERVER 6027R-TRF USER'S MANUAL
Universal Serial Bus (USB)
Four Universal Serial Bus ports (USB
0/1, USB 2/3) are located on the
I/O back panel. Please note that BP
USB 2/3 can also be used for PS2
Keyboard/Mouse connections. In
addition, three USB headers, located
close to the IO Hub, provides six front-
accessible USB connections (USB 4/5,
USB 8/9, USB 10/11). One Type A
connector (USB6) also supports front
panel USB connection. (Cables are not
included). See the tables on the right
for pin defi nitions.
FP USB (4/5, 8/9, 10/11, USB 6)
Pin Defi nitions
USB 4, 8,10, 6, 7
Pin # Defi nition
USB 5, 9, 11
Pin # Defi nition
1 +5V 1 +5V
2 PO- 2 PO-
3 PO+ 3 PO+
4 Ground 4 Ground
5 NC 5 Key
(NC = No connection)
Backplane
USB (0/1, 2/3)
Pin Defi nitions
Pin# Defi nition
1 +5V
2 PO-
3 PO+
4 Ground
5NA
Ethernet Ports
Two Gigabit Ethernet ports (LAN1,
LAN2) are located on the I/O backplane
on the motherboard. In addition, an
IPMI_Dedicated LAN is located above
USB 0/1 ports on the backplane to
provide KVM support for IPMI 2.0. All
these ports accept RJ45 type cables.
Please refer to the LED Indicator
Section for LAN LED information.
LAN Ports
Pin Defi nition (LAN 1/2)
Pin# Defi nition Pin# Defi nition
1 P2V5SB 10 SGND
2 TD0+ 11 Act LED
3 TD0- 12 P3V3SB
4 TD1+ 13 Link 100 LED
(Yellow, +3V3SB)
5 TD1- 14 Link 1000 LED
(Yellow, +3V3SB)
6 TD2+ 15 Ground
7 TD2- 16 Ground
8 TD3+ 17 Ground
9 TD3- 18 Ground
(NC = No Connection)
