SUPERSERVER 6027R-TRF USER'S MANUAL

Note: For the memory modules to work properly, please install DIMM modules in

pairs (with an even number of DIMMs installed).

Note: All channels in a system will run at the fastest common frequency.

5-6 Adding PCI Add-On Cards

The 6027R-TRFcan accommodate six low-proﬁ le PCI add-on cards.

Installing an Add-on Card

1. Begin by removing the shield for the PCI slot you wish to populate.

2. Fully seat the card into the slot, pushing down with your thumbs evenly on

both sides of the card.

3. Finish by using a screw to secure the top of the card shield to the chassis.

The PCI slot shields protect the serverboard and its components from EMI

and aid in proper ventilation, so make sure there is always a shield covering

each unused slot.
