SUPERSERVER 6027R-TRF USER'S MANUAL
DVD-ROM Installation (Optional)
The SC825 chassis supports the installation of an optional DVD-ROM drive into
the front of the chassis. The top cover of the chassis must be opened to gain full
access to the DVD-ROM drive bay. The SuperServer 6027R-TRF accomodates only
slim type DVD-ROM drives. Side mounting brackets are typically needed to mount
a slim DVD-ROM drive in the server.
Accessing the Inside of the Chassis
1. Grasp the two handles on either side and pull the unit straight out until it
locks (you will hear a "click").
2. Next, depress the two buttons on the top of the chassis to release the top
cover and at the same time, push the cover away from you until it stops. You
can then lift the top cover from the chassis to gain full access to the inside of
the server.
Warning: To prevent direct exposure to the laser beam and hazardous radiation
exposure, do not open the enclosure or use the unit in any unconventional way.
