Chapter 2: Server Installation
2-5
Figure 2-1: Separating the Rack Rails
Separating the Inner and Outer
Rails
1. Locate the rail assembly in the
chassis packaging.
2. Extend the rail assembly by
pulling it outward.
3. Press the quick-release tab.
4. Separate the inner rail
extension from the outer rail
assembly.
1
1
1
2
1
4
1
3
Rail Assembly
Extending the Rails
Quick-Release Tab
Separating
the Inner Rail
Extension
