Chapter 7: BIOS
7-7
Energy Performance
The options are Performance, Balanced Performance, Balanced Energy, and
Energy Effi cient.
Factory Long Duration Power Limit
This item displays the power limit set by the manufacturer during which long
duration power is maintained.
Long Duration Power Limit
This item displays the power limit set by the manufacturer during which long
duration power is maintained.
Factory Long Duration Maintained
This item displays the period of time set by the manufacturer during which long
duration power is maintained.
Long Duration Maintained
This item displays the period of time during which long duration power is
maintained.
Recommended Short Duration Power
This item displays the short duration power settings recommended by the
manufacturer.
Short Duration Power Limit
This item displays the period of time during which short duration power is
maintained.
