D-2

X10SLH-F User’s Manual

D-2 Steps to Reboot the System by Using Jumper JBR1

(Available when JBR1 is Installed onboard)

1. Power down the system.

2. Close pins 2-3 on Jumper JBR1, and power on the system.

3. Follow the BIOS recovery SOP listed in the previous chapter (Appendix C).

4. After completing the steps above, power down the system.

5. Close pins 1-2 on Jumper JBR1, and power on the system.
