X10SLH-F User’s Manual

1-2 Chipset Overview

The X10SLH-F supports a single Intel

Xeon E3-1200 v3 and 4th Generation

Core™ i3, Pentium, Celeron processors in an LGA 1150 H3 socket. Built upon the

functionality and the capability of the C226 Express chipset, the motherboard

provides substantial enhancement to system performance and storage capability

for high performance platforms in a sleek package.

The high-speed Direct Media Interface (DMI) featured in the Intel

C226 Express

chipset supports high-speed Direct Media Interface (DMI) for chip-to-chip true iso-

chronous communication, providing up to 10 Gb/s of software-transparent data

transfer rate on each read/write direction. In addition, the X10SLH-F also features

a TCO timer which allows the system to recover from a software/hardware lock

and perform tasks, including Function Disable and Intruder Detect.

Intel C226 Express Chipset Features

• Direct Media Interface (up 10 Gb/s transfer, Full Duplex)

• Intel

Matrix Storage Technology and Intel Rapid

Storage Technology

• Dual NAND Interface

• Intel

I/O Virtualization (VT-d) Support

• Intel

Rapid Storage Technology Support

• Intel

Trusted Execution Technology Support

• PCI Express 2.0 Interface (up to 5.0 GT/s)

• SATA Controller (up to 6Gb/sec)

• Advanced Host Controller Interface (AHCI)

• Intel

Active Management Technology (iAMT) 9.0 and vPRO 9.0 support
