Chapter 1: Introduction
1-5
X10SLH-F Jumpers
Jumper Description Default
JBT1 CMOS Clear (See Chpt. 2)
JI
2
C1/JI
2
C2 SMB to PCI Slots Off (Disabled)
JPG1 VGA Enable Pins 1-2 (Enabled)
JPL1/JPL2 LAN1/LAN2 Enable Pins 1-2 (Enabled)
JPME1 ME Recovery Pins 1-2 (Normal)
JPME2 Manufacturer Mode Pins 1-2 (Normal)
JPUSB1 USB4/5 Wake_Up Enable Pins 2-3 (Disabled)
JWD1 Watch Dog Enable Pins 1-2 (RST)
X10SLH-F Headers/Connectors
Connector Description
Battery Onboard Battery
COM1/COM2 COM1/COM2 Port Headers
Fan1-Fan4, FanA System/CPU Fan Headers
J14 (See USB 1 =(3.0)) Vertical USB 1 (3.0) Connector
JF1 Front Panel Control Header
JL1 Chassis Intrusion Header
JLED1 Power LED Indicator Header
JPI
2
C1 Power System Management Bus (Power SMB)
JPW1 24-pin ATX Main Power Connector (Required)
JPW2 +12V 8-pin CPU power Connector (Required)
JSD1 SATA DOM (Device_On_Module) Power Connector
JSTBY1 Standby Power Header
JTPM1 Trusted Platform Module/Port 80 Connector
LAN1/LAN2 Gigabit (RJ45) Ports (LAN1/2)
SPKR1 Internal Speaker/Buzzer
I-SATA0-5 (SATA 3.0) (Intel PCH) Serial ATA (SATA 3.0) Ports 0-5 (6Gb/sec)
(CPU) Slot 6 PCI-Express 3.0 x8 in x16 Slot
(CPU) Slot 5 PCI-Express 3.0 x8 Slot
(PCH) Slot 4 PCI-Express 2.0 x4 in x8 Slot
SW1 Unit Identier (UID) Switch
T-SGPIO 1/2 Serial_Link General Purpose I/O Connection Headers 1/2
USB 0 (3.0)/USB 1 (3.0) USB 3.0 Port 0/USB 3.0 Vertical Header 1
USB 2/3 Backpanel USB Ports 2/3
USB 4/5 Backpanel USB 2.0 Ports 4/5
