Tp-Link td-w8950n [12/98] Chapter 2 connecting the modem router

TD-W8950N 150Mbps Wireless N ADSL2+ Modem Router User Guide

Chapter 2. Connecting the Modem Router

2.1 System Requirements

 Broadband Internet Access Service (DSL/Cable/Ethernet).

 PCs with a working Ethernet Adapter and an Ethernet cable with RJ45 connectors.

 TCP/IP protocol on each PC.

 Web browser, such as Microsoft Internet Explorer, Mozilla Firefox or Apple Safari.

2.2 Installation Environment Requirements

 The Product should not be located where it will be exposed to moisture or excessive heat.

 Place the router in a location where it can be connected to the various devices as well as to a

power source.

 Make sure the cables and power cord are safely placed out of the way so they do not create a

tripping hazard.

 The router can be placed on a shelf or desktop.

 Keep away from the strong electromagnetic radiation and the device of electromagnetic

sensitive.

Generally, TD-W8950N is placed on a horizontal surface. The device also can be mounted on the

wall as shown in Figure 2-1.

Figure 2-1 Wall-mount Install



Note:

The diameter of the screw, 3.5mm<D<8mm, and the distance of two screws is 107.5mm. The

screw that project from the wall need around 4mm based, and the length of the screw need to be

at least 20mm to withstand the weight of the product.
