TD-W8950N 150Mbps Wireless N ADSL2+ Modem Router User Guide

You can check

it by following the steps below:

1) Is the connection between your PC and the router correct?

The LED of LAN port which you link to the device and the LEDs on your PC's adapter should

be lit.

2) Is the TCP/IP configuration for your PC correct?

If the router's IP address is 192.168.1.1, your PC's IP address must be within the range of

192.168.1.2 - 192.168.1.254.

3.2 Quick Installation Guide

With a Web-based utility, it is easy to configure and manage the TD-W8950N 150Mbps Wireless N

ADSL2+ Modem Router. The Web-based utility can be used on any Windows, Macintosh or UNIX

OS with a Web browser, such as Microsoft Internet Explorer, Mozilla Firefox or Apple Safari.

1. To access the configuration utility, open a web-browser and type the default address

http://tplinkmodem.net/

in the address field of the browser.

Figure 3-3

After a moment, a login window will appear, similar to the Figure 3-4. Enter admin for the

User Name a

nd Password, both in lower case letters. Then click the Login button or press the

Enter key.

Figure 3-4



Note:

1) Do not mix up the user name and password with your ADSL account user name and password

which are needed for PPP connections.

2) If the above screen does not pop up, it means that your Web-browser has been set to a proxy.

Go to Tools menu→Internet Options→Connections→LAN Settings, in the screen that

appears, cancel the Using Proxy checkbox, and click OK to finish it.
