Technical Data

32 312668Z

Technical Data

* Tested in No. 10W motor oil. Flow rates vary with fluid pressure, temperature and viscosity.

** Battery required to meet safety approvals: Duracell

MN1604 or Eveready

EN22, 522

† At 2.5 gpm (9.5 lpm), at 70°F (21°C), with 10W motor oil and 1 gallon (3.8 l) dispensed. May require calibration;

out-of-box accuracy is +/-1.25 percent.

Duracell

is a registered trademark of Duracell Inc.

Eveready

is a registered trademark of the Eveready Battery Co., Inc.

Flow range* 0.1 to 5 gpm (0.4 to 19 lpm)

Maximum Working Pressure 1000 psi (69 bar)

Weight 3 lbs (1.36 kg)

Dimensions without extension/nozzle

Length

Width

Height

11 inches (28 cm)

3.25 inches (8.3 cm)

Inlet 1/2” npt, 1/2” BSPP, 1/2” BSPT

Outlet 3/8” npt

Operating temperature range 32°F to 120°F (0°C to 49°C)

Storage temperature range -30°F to 120°F (-34°C to 49°C)

Battery** 9 volt alkaline

Wetted parts stainless steel, nitrile rubber, zinc, CS, LCP

Fluid compatibility lubricating oils, antifreeze mixtures

Pressure loss

Accuracy†

90 psi (1.2 bar) @ 5 GPM

+/- 0.5 percent

Units of measurement

Maximum totalizer amount

Maximum recorded dispensed volume

Maximum preset volume (LDP5 Meter only)

pints, quarts, gallons, liters (factory set in quarts)

99,999 units

999.99 units

999.9 units
