Installation
334513D 17
Choosing an Installation
Location
• Select a location that will adequately support the
weight of the pump, as well as all plumbing and
electrical connections.
• Refer to the mounting hole layout provided in
Dimensions starting on page 51.
• Always mount the pump upright.
• If you have a mounting configuration that requires
installation in a manner different than depicted in
F
IG. 5 or FIG. 6, please contact your Graco distribu-
tor for assistance.
Fluid Connections
1. Remove and discard plugs on check valves.
2. Connect a 1/4 npt(f) fluid line from the fluid source to
the inlet check valve (K). See F
IG. 5 on page 15, or
F
IG. 6 on page 16.
3. Install a pressure relief valve (F) on the outlet side of
the pump.
NOTE: A pressure relief valve is available from Graco
and can be connected back to the tank or directly to the
inlet side of the pump. See Kits and Accessories on
page 49.
4. Set the pressure relief valve at or below the maxi-
mum working pressure of the pump.
5. Connect a 1/4 npt(f) fluid line from the outlet check
valve (L) to the injection point.
6. Connect a 10-32 UNF fluid outlet from the
prime/bleed valve (21) to the fluid source or waste
reservoir.
Motor Electrical Connections
In the event of an injection line blockage, to reduce the
risk of skin injection and damage to the pump, ensure
the pressure relief valve is set at or below the maxi-
mum working pressure of the pump.
To reduce the risk of electrical shock;
• All electrical wiring must be done by a qualified
electrician and comply with all local codes and reg-
ulations.
• Install the pump with a dedicated means to discon-
nect the main power to the pump.
NOTICE
Branch circuit protection (user supplied) is required on
all models. To avoid equipment damage:
• Never operate the pump without branch circuit
protection installed.
• Branch circuit protection of the correct voltage
and amperage must be installed in line with the
power entry to the system.
• Branch circuit protection should be UL248
approved.
• See table below for branch circuit protection
rating.
Configuration
Minimum
Voltage
Branch Circuit
Protection
Rating
CI-12S-xxx-xxx-x
12 VDC
15 A
CI-12L-xxx-xxx-x
12 VDC
20 A
CI-12H-xxx-xxx-x
12 VDC
25 A
CI-24H-xxx-xxx-x
24 VDC
15 A
CI-1AL-xxx-xxx-x
115 VAC
3 A
CI-2AL-xxx-xxx-x
230 VAC
2 A
CI-3AH-xxx-xxx-x
115 VAC
(Single Phase)
5 A
CI-3AH-xxx-xxx-x
230 VAC
(Single Phase)
3 A
CI-4AL-xxx-xxx-x
230 VAC
(3 Phase)
1 A
CI-4AL-xxx-xxx-x
460 VAC
(3 Phase)
1 A
CI-4AH-xxx-xxx-x
230 VAC
(3 Phase)
1.25 A
CI-4AH-xxx-xxx-x
460 VAC
(3 Phase)
1 A
