Technical Data
334513D 61
Technical Data
Wolverine Chemical Injection Pump
US Metric
Maximum fluid working pressure Varies by model. See Models and Approvals on page 3.
Input Voltage
CI-12x-xxx-xxx-x 12 VDC
CI-24x-xxx-xxx-x 24 VDC
CI-1Ax-xxx-xxx-x 115 VAC
CI-2Ax-xxx-xxx-x 230 VAC
CI-3Ax-xxx-xxx-x 115 VAC or 230 VAC 3 Single Phase
CI-4Ax-xxx-xxx-x 230 VAC or 460 VAC 3 Phase
Maximum Input Current
CI-12S-xxx-xxx-x 11 A @ 12 VDC
CI-12L-xxx-xxx-x 16 A @ 12 VDC
CI-12H-xxx-xxx-x 23 A @ 12 VDC (Intermittent duty cycle, see page 24)
CI-24H-xxx-xxx-x 12 A @ 24 VDC
CI-1Ax-xxx-xxx-x 2.0 A @ 110 VAC Single Phase
CI-2Ax-xxx-xxx-x 1.2 A @ 230 VAC Single Phase
CI-3AH-xxx-xxx-x 4.8 A @ 110 VAC Single Phase
CI-3AH-xxx-xxx-x 2.4 A @ 230 VAC Single Phase
CI-4AL-xxx-xxx-x 0.59 A @ 230 VAC 3 Phase
CI-4AL-xxx-xxx-x 0.30 A @ 460 VAC 3 Phase
CI-4AH-xxx-xxx-x 1.1 A @ 230 VAC 3 Phase
CI-4AH-xxx-xxx-x 0.55 A @ 460 VAC 3 Phase
Power Connection See Motor Electrical Connections on page 17.
Environmental temperature range, ordinary location -40°–176°F -40°–80°C
Environmental temperature range, hazardous loca-
tion
-13°–104°F -25°–40°C
Noise (dBa)
Maximum sound pressure
<70 dBa
Inlet/Outlet Sizes
Fluid inlet size 1/4 in. npt(f)
Fluid outlet size 1/4 in. npt(f)
Materials of Construction
Pump/Check Valve Seal Material
See Configuration Chart on page 6 for seal material. All other
packing materials are PEEK and PTFE unless otherwise noted.
Wetted Parts
See Configuration Chart on page 6 for plunger material. All
other materials are 316 stainless steel unless otherwise noted.
Weight
Wolverine Basic 31 lb. 14 kg
Wolverine Advanced,1 pump (Simplex) 35 lb. 16 kg
Wolverine Advanced, 2 pumps (Duplex) 39 lb. 18 kg
Wolverine Hazardous Location,1 pump (Simplex) 72 lb. 33 kg
Wolverine Hazardous Location, 2 pumps (Duplex) 76 lb. 34 kg
