Kits and Accessories
334513D 49
Kits and Accessories
Wolverine (All)
Wolverine Advanced and Hazardous Location
Part No. Description
B32038 FKM Inlet and Outlet Check Valve Repair Kit
(includes ref. 24b, 25b, 25e)
B32039 FKM ETP Inlet and Outlet Check Valve Repair
Kit (includes ref. 24b, 25b, 25e)
B32040 FFKM Inlet and Outlet Check Valve Repair Kit
(includes ref. 24b, 25b, 25e)
B32111 HNBR Inlet and Outlet Check Valve Repair Kit
(includes ref. 24b, 25b, 25e)
B32157 316 SST Ball Valve Kit, 3/4 NPT (F)
B32075 Electric Motor Brush Repair Kit (not Hazardous
Location)
B32045 225-750 PSI Pressure Relief Valve Kit
B32046 750-1500 PSI Pressure Relief Valve Kit
B32047 1500-2250 PSI Pressure Relief Valve Kit
B32048 2250-3000 PSI Pressure Relief Valve Kit
B32049 3000-4000 PSI Pressure Relief Valve Kit
B32050 4000-5000 PSI Pressure Relief Valve Kit
B32051 5000-6000 PSI Pressure Relief Valve Kit
Part No. Description
A30300
3/16” FKM: Chromex Fluid Module
*
A30301
3/16” FKM ETP: Chromex Fluid Module
*
A30302
3/16” HNBR: Chromex Fluid Module
*
A30303
3/16” FFKM: Chromex Fluid Module
*
A30310
3/16” FKM: Ceramic Fluid Module
*
A30311
3/16” FKM ETP: Ceramic Fluid Module*
A30312
3/16” HNBR: Ceramic Fluid Module
*
A30313
3/16” FFKM: Ceramic Fluid Module
*
A30400
1/4” FKM: Chromex Fluid Module*
A30401
1/4” FKM ETP: Chromex Fluid Module
*
A30402
1/4” HNBR: Chromex Fluid Module
*
A30403
1/4” FFKM: Chromex Fluid Module*
A30410
1/4” FKM: Ceramic Fluid Module
*
A30411
1/4” FKM ETP: Ceramic Fluid Module
*
A30412
1/4” HNBR: Ceramic Fluid Module*
A30413
1/4” FFKM: Ceramic Fluid Module
*
A30500
3/8” FKM: Chromex Fluid Module
*
A30501
3/8” FKM ETP: Chromex Fluid Module
*
A30502
3/8” HNBR: Chromex Fluid Module
*
A30503
3/8” FFKM: Chromex Fluid Module
*
A30510
3/8” FKM: Ceramic Fluid Module
*
A30511
3/8” FKM ETP: Ceramic Fluid Module
*
A30512
3/8” HNBR: Ceramic Fluid Module
*
A30513
3/8” FFKM: Ceramic Fluid Module
*
A30600
1/2” FKM: Chromex Fluid Module
*
A30601
1/2” FKM ETP: Chromex Fluid Module
*
A30602
1/2” HNBR: Chromex Fluid Module
*
A30603
1/2” FFKM: Chromex Fluid Module
*
A30610
1/2” FKM: Ceramic Fluid Module*
A30611
1/2” FKM ETP: Ceramic Fluid Module
*
A30612
1/2” HNBR: Ceramic Fluid Module
*
A30613
1/2” FFKM: Ceramic Fluid Module*
A30700
5/8” FKM: Chromex Fluid Module
*
A30701
5/8” FKM ETP: Chromex Fluid Module
*
A30702
5/8” HNBR: Chromex Fluid Module*
A30703
5/8” FFKM: Chromex Fluid Module
*
A30710
5/8” FKM: Ceramic Fluid Module
*
A30711
5/8” FKM ETP: Ceramic Fluid Module
*
A30712
5/8” HNBR: Ceramic Fluid Module
*
A30713
5/8” FFKM: Ceramic Fluid Module
*
A30800
3/4” FKM: Chromex Fluid Module
*
A30801
3/4” FKM ETP: Chromex Fluid Module
*
