Graco Wolverine Basic [53/62] Wolverine hazardous location pump dimensions
![Graco Wolverine Basic [53/62] Wolverine hazardous location pump dimensions](/views2/1193746/page53/bg35.png)
Dimensions
334513D 53
Wolverine Hazardous Location Pump Dimensions
FIG. 38 Wolverine Hazardous Location Pump Dimensions
A B C D E F G H J K L
AC
Pump
16.3 in.
(41.4 cm)
8.9 in.
(22.6 cm)
4.5 in.
(11.4 cm)
2.85 in.
(7.2 cm)
19.6 in.
(49.8 cm)
9.6 in.
(25.1 cm)
7.5 in.
(19.8 cm)
5.0 in.
(12.7 cm)
0.281 in. dia
(0.714 cm)
23.7 in.
(60.2 cm)
19.6 in.
(49.8 cm)
DC
Pump
16.3 in.
(41.4 cm)
8.9 in.
(22.6 cm)
4.5 in.
(11.4 cm)
2.85 in.
(7.2 cm)
17.6 in.
(44.7 cm)
9.6 in.
(25.1 cm)
7.5 in.
(19.8 cm)
5.0 in.
(12.7 cm)
0.281 in. dia
(0.714 cm)
23.7 in.
(60.2 cm)
--
