Parts
48 334513D
Table 10: Inlet Check Valve
Table 11: Outlet Check Valve
Ref
Part Numbers by Fluid Plunger Size Diameter
Qty.3/16 in. 1/4 in. 3/8 in. 1/2 in. 5/8 in. 3/4 in.
FKM
24 B32216 B32024 B32024 B32024 B32024 B32024
1
FKMETP
24 B32218 B32026 B32026 B32026 B32026 B32026
1
HNBR
24 B32220 B32028 B32028 B32028 B32028 B32028
1
FFKM
24 B32222 B32113 B32113 B32113 B32113 B32113
1
Ref
Part Numbers by Fluid Plunger Size Diameter
Qty.3/16 in. 1/4 in. 3/8 in. 1/2 in. 5/8 in. 3/4 in.
FKM
25 B32217 B32025 B32025 B32025 B32025 B32025
1
FKMETP
25 B32219 B32027 B32027 B32027 B32027 B32027
1
HNBR
25 B32221 B32029 B32029 B32029 B32029 B32029
1
FFKM
25 B32223 B32114 B32114 B32114 B32114 B32114
1
