Parts
334513D 47
Table 7: Packing, including Plunger Bearing, qty 2 (ref. 39)
Table 8: Fluid Cylinder
Table 9: Fluid Plunger
Ref
Part Numbers by Fluid Plunger Size Diameter
Qty.3/16 in. 1/4 in. 3/8 in. 1/2 in. 5/8 in. 3/4 in.
FKM
41 B32429 B32430 B32431 B32432 B32433 B32434
1
FKMETP
41 B32436 B32437 B32438 B32439 B32440 B32441
1
HNBR
41 B32443 B32444 B32445 B32446 B32447 B32448
1
FFKM
41 B32450 B32451 B32452 B32453 B32454 B32455
1
AFLAS
41 B32041 B32042 B32043 B32044 B32085 B32086
1
Ref
Part Numbers by Fluid Plunger Size Diameter
Qty.3/16 in. 1/4 in. 3/8 in. 1/2 in. 5/8 in. 3/4 in.
FKM
42 B32482 B32483 B32484 B32485 B32486 B32487
1
FKMETP
42 B32516 B32517 B32518 B32519 B32520 B32521
1
HNBR
42 B32523 B32524 B32525 B32526 B32527 B32528
1
FFKM
42 B32530 B32531 B32532 B32533 B32534 B32535
1
Ref
Part Numbers by Fluid Plunger Size Diameter
Qty.3/16 in. 1/4 in. 3/8 in. 1/2 in. 5/8 in. 3/4 in.
Ceramic
43 B32543 B32544 B32545 B32546 B32547 B32548
1
Chromex-Coated 17-4 Stainless Steel
43 B32543 B32544 B32545 B32546 B32547 B32548
1
