Graco Therm-O-Flow 20 [53/108] Replace fan
![Graco Therm-O-Flow 20 [53/108] Replace fan](/views2/1193755/page53/bg35.png)
Repair
Replace Replace
Replace
Fan Fan
Fan
1.Turnthemainpowerswitchoff.
2.Disconnectplugfrompoweroutletorturnoff
circuitbreakerforincomingpower.
3.Openelectricalenclosuredoor.
4.RemoveconnectorfromJ7connectoronAWB
board.Removered(+)andblack(-)fanwires
fromconnector.
5.Cutanycabletiesbetweentheendofthefan
wirestothefan(136).
6.Removescrews(141),grill(137),fournuts(139),
rearfangrill(138),andfan(136).
7.Mountnewfan(136),rearfangrill(138),and
nuts(139)ongrill(137)withthearrowpointing
towardthegrill(137).
8.Tiedownfanwiresontotiedownlocationson
grill(137)usingcablezipties.
9.Routefanwiresintotheelectricalenclosure.
ConnectredandblackfanwirestoJ7connector.
ReconnectJ7connectortoAWB.Usecableties
tosecurefanwirestoothercablesinelectrical
enclosure.
Note
TopreventfanerrorsonADM,remove
excessslackandensurecablingandzip
tiesdonotcontactfanblades.
10.Reinstallfangrill(137)andclosetheelectrical
enclosure.
334129D53
