Parts
NXT NXT
NXT
6500, 6500,
6500,
70:1 70:1
70:1
Pump Pump
Pump
Modules Modules
Modules
1
Torqueto50–60ft-lb(68–81n•m).
2
Torqueto145–155ft-lbs(196–210n•m).
3
Coatmountingsurfaceofsensormountingblock
withnon-siliconeheatsinkcompound.donotcoat
sensor.
4
Priortotighteningbandclamp(412)rtdsensor
(410)mustbefullycontainedwithinthesensor
mount(411).
5
Coatinsideofheater(407a,407b)onlytowithin
3/4inofverticalends,withnon-siliconeheatsink
compoundbeforemounting.
6
Torqueto150ft-lbs(203n•m).
7
Applyanaerobicsealant.
78334129D
