36
Figure
● Push the telescopic tube into the connecting piece
on the floor tool until it locks in place.
● To release the connection, press the locking collar
a
nd pull out the telescopic tube.
Figure
● Move the sliding sleeve in the direction of the arrow
to release the telescopic tube and adjust it to the
length required.
F
igure
● Holding the power cord by the plug, pull out to the
required length and insert the plug into the mains
socket.
Figure Switching on/off
●
To switch the vacuum cleaner on or off, press the
ON/OFF button.
Figure Controlling the suction level
The required suction level can be set to the level
required by turning the control knob in the direction
of the arrow.
Low power range =>
For vacuuming delicate
materials, e.g curtains.
Medium power range =>
For the daily vacuuming of light
dirt deposits.
High power range =>
For vacuuming durable floor coverings,
hard floors and heavy deposits of dirt.
Vacuuming
!
Please note:
Depending on the type of hard floor involved (e.g.
rough rustic tiles), floor tools are subject to a certain
amount of wear. Therefore, you must check the
underside of the floor tool at regular intervals. Worn
undersides of floor tools may have sharp edges that
can damage sensitive hard floors, such as parquet or
linoleum. The manufacturer does not accept any
responsibility for damage caused by worn floor tools.
Figure
Adjusting the floor tool:
Rugs and carpets =>
Hard floors =>
Figure
● Remove the crevice nozzle or upholstery nozzle from
the accessories compartment in the appliance lid.
7*
8
9
10
11
12
6
*
Figure Vacuuming with accessories
Attach the nozzles to the suction pipe or handle as
required:
a)Crevice nozzle for vacuuming crevices and corners, etc.
b
)Upholstery nozzle for vacuuming upholstered
furniture, curtains, etc.
c)Hard-floor tool
For vacuuming hard floor coverings
(tiles, parquet flooring, etc.)
● Push the telescopic tube into the connecting piece
o
f the hard floor tool until it locks in place.
●
To release the connection, press the locking collar
and pull out the telescopic tube.
Figure Professional upholstery nozzle
● For intensive cleaning of upholstered furniture
(attach to the handle or suction pipe, depending on
requirements).
●
To clean the professional upholstery nozzle, simply
vacuum it using the handle.
● If it is very dirty, the professional upholstery nozzle
can also be opened. To do this, turn the two screws
on the sides of the nozzle (e.g. using a coin) and
remove the inner part from the nozzle.
● After cleaning, replace the inner part (make sure it is
correctly seated) and screw to the housing.
Figure
● After use, place the crevice or upholstery nozzle back
into the accessories compartment in the appliance
lid.
Turbo brush
If your appliance is equipped with a turbo brush,
consult the accompanying instruction manual for
instructions on its use and maintenance.
Figure
● You can use the parking aid on the back of the
appliance if you wish to stop vacuuming for a short
time.
● Once you have switched off the appliance, slide the
hook on the floor tool into the recess on the rear of
the appliance.
Figure
To overcome obstacles, e.g. steps, the appliance can
also be carried by the handle on the appliance body.
When the work is done
Figure
● Pull out the mains plug.
● Tug the power cord briefly and then let go
(the power cord retracts automatically).
Figure
● To store or transport the appliance, you can use the
storage aid on the underside of the appliance.
● Stand the appliance up on its end. Slide the catch on
the floor tool into the groove on the underside of the
appliance.
1
3*
1
4*
15
16
17
18
19
*
Dependent on model
GA 9000 849 146_BSGL5_GL50 06.02.2013 08:15 Seite 36
