37
Changing the filter
!
Please note: Always switch off the appliance before
changing the filter.
Replacing the bag
Figure
a)If the dust bag change indicator lights up red
continuously when the floor tool is lifted from the
floor and the highest power setting has been
selected, the dust bag must be changed, even
t
hough it may not yet be full. Even if the dust bag is
n
ot full, it may still need changing, due to the type of
dust which has been vacuumed.
First check that the nozzle, suction pipe and flexible
hose are not blocked, as this would also lead to the
dust bag change indicator being triggered.
b)The handle can easily be detached from the hose to
r
emove blockages.
Figure Opening the lid
● Open the lid by moving the locking lever in the
direction of the arrow.
Figure
a)Seal the dust bag by pulling the sealing plate, and
remove the bag.
b)Slide the new dust bag into the holder up to the stop.
!
Please note: the lid will only close if a dust bag has
been inserted.
Cleaning the motor protection filter
The motor protection filter should be cleaned regularly
by tapping out the dirt and rinsing.
Figure
● Open the dust bag compartment lid.
Figure
● Remove the motor protection filter from
the appliance in the direction of the arrow.
● Disconnect the motor protection filter from the Bionic
filter.*
● Clean the motor protection filter by tapping out the
dirt.
● If it is very dirty, the motor protection filter should be
rinsed. The filter must then be left to dry for at least
24 hours.
!
Please note: the Bionic filter must not come into
contact with water, as this will adversely affect the
correct operation of the filter.
● After cleaning, place the Bionic filter onto the motor
protection filter as necessary and push both filters
into the appliance.
● Close the dust bag compartment lid.
Replacing the Bionic filter
If your appliance is equipped with a Bionic filter, it
should be replaced once it begins to lose its effect
(after approx. 1 year).
20*
21
22
23*
2
1
Figure
●
Open the dust bag compartment lid.
Figure
● Remove the motor protection filter together with the
Bionic filter from the appliance.
● Remove the old Bionic filter from the motor
protection filter and dispose of it.
●
Place the Bionic filter onto the motor protection filter.
● Push the filters into the appliance and close the dust
bag compartment lid.
●
The motor protection filter must also be inserted into
the appliance if you no longer wish to use the Bionic
filter
Replacing the exhaust filter
Replacing the micro-hygiene filter
This should be replaced with every replacement filter pack.
Figure
● Open the dust bag compartment lid.
Figure
● Release the filter holder by turning the locking lever
in the direction of the arrow.
● Remove the micro-hygiene filter. Insert the new
micro-hygiene filter into the appliance.
● Insert the filter holder in the appliance and lock it in
place.
Replacing the HEPA filter
If your vacuum cleaner is equipped with a HEPA filter,
this should be replaced once a year.
Figure
● Open the dust bag compartment lid.
Figure
● Unlock the Hepa filter by turning the locking lever in
the direction of the arrow and remove the filter from
the appliance.
● Insert the new HEPA filter and lock it in place.
If you have vacuumed up fine dust particles, clean the
motor protection filter and, if necessary, replace the
micro-hygiene filter or HEPA filter.
Care
Always switch off the vacuum cleaner and disconnect
it from the mains before cleaning the vacuum cleaner.
The vacuum cleaner and plastic accessories can be
cleaned with a commercial plastic cleaner.
!
Do not use abrasive agents, glass or all-purpose
cleaning products. Never immerse the vacuum
cleaner in water.
If necessary, the dust compartment can be cleaned
with a second vacuum cleaner or simply wiped with
a dry cloth or dusting brush.
Subject to technical modifications.
25
21
26*
21
2
4*
21
*
Dependent on model
GA 9000 849 146_BSGL5_GL50 06.02.2013 08:15 Seite 37
