EM-1240-LX User’s Manual Introduction
Internal SD Socket
The EM-1240-LX provides an internal SD socket for storage expansion. It allows users to plug in
a Secure Digital (SD) memory card compliant with the SD 1.0 standard for up to 1 GB of
additional memory space. To install an additional SD card, you must first remove the
EM-1240-LX’s outer cover to access the slot. The internal SD socket is located on the backside of
the EM-1240-LX’s bottom board; you can find the SD plug-in slot at the right of the EM-1240-LX,
lower than the cover screw. Plug the SD card into the socket directly and remember to press the
SD card first if you want to take it out. Please note that the SD function shares the same chipset
with the DIO. If you would like to enable the SD function, the DIO must be disabled. If you would
like to enable the DIO, the SD function must be disabled.
Additional Functions
Reset Button
Press the Reset button on the EM-1240-DK continuously for at least 5 seconds to load the factory
default configuration. After the factory default configuration has been loaded, the system will
reboot automatically. We recommend that you only use this function if the software is not working
properly and you want to load factory default settings. To reset an embedded Linux system, always
use the software reboot command />reboot to protect the integrity of data being transmitted or
processed. The Reset button is not designed to hard reboot the EM-1240 Development Kit.
ATTENTION
Resetting to factory defaults will not format the user directory and erase all of the user’s data.
Loading factory defaults will only load the configuration file. The files in the EM-1240-LX that
will be replaced include:
a. /etc/boa.conf
b. /etc/hosts
c. /etc/inittab
d. /etc/password
e. /etc/ramfs.img
f. /etc/resolv.conf
g. /etc/version
h. /etc/group
i. /etc/inetd.conf
j. /etc/motd
k. /etc/protocols
l. /etc/rc
m. /etc/services
n. /home/httpd/index.html
ATTENTION
This function only takes effect when the user directory is working correctly. If the user directory
has crashed, the kernel will automatically load the factory defaults.
1-11
