EM-1240-LX User’s Manual Software Package
Flash Context Flash Address Size Access control
Boot loader 0 – 0x3ffff 256 K Read ONLY
Kernet &
Root File System
0x40000– 0x3fffff 4 M Read ONLY
JFFS2
User Directory 0x400000 – 0x7fffff 4 M – 256 K Read / Write
JFFS2
Developers should store their own programs only to partitions /etc, /home, /tmp, and /usr/bin. In
addition, executable files should be stored in /usr/bin, as doing so will allow developers to use
hotkeys.
In addition to the flash file systems, a RAM based file system is mounted on /var/.
Journaling Flash File System (JFFS2)
The flash User Directory is formatted by the Journaling Flash File System (JFFS2), which places a
compressed file system on the flash, transparent to the user.
Axis Communications in Sweden developed the Journaling Flash File System (JFFS2).
JFFS2 provides a file system directly on flash, rather than emulating a block device designed for
use on flash-ROM chips. It recognizes flash-ROM chips’ special write requirements, does
wear-leveling to extend flash life, keeps the flash directory structure in RAM at all times, and
implements a log-structured file system that is always consistent—even if the system crashes or
unexpectedly powers down. It does not require fsck on boot up.
JFFS2, a later version of JFFS, provides improved wear-leveling and garbage-collection
performance, improved RAM footprint and response to system-memory pressure, improved
concurrency and support for suspending flash erases, marking of bad sectors with continued use of
the remaining good sectors (thus enhancing the write-life of the devices), native data compression
inside the file system design; and support for hard links.
Key features of JFFS2 are:
y Directly targeted to Flash ROM
y Robust
y Consistent across power failure
y No integrity scan (fsck) is required at boot time after normal or abnormal shutdown
y Explicit wear leveling
y Transparent compression
Although JFFS2 is a journaling file system, this does not preclude the loss of data. The file system
will remain in a consistent state across power failures, and will always be mountable. However, if
the board is powered down during a write, then the incomplete write will be rolled back on the
next boot. Any writes that were already completed will not be affected.
Additional information about JFFS2 is available at
http://sources.redhat.com/jffs2/jffs2.pdf
http://developer.axis.com/software/jffs/
http://www.linux-mtd.infradead.org/
3-3
