EM-1240-LX User’s Manual Getting Started
Telnet
If you know at least one of the
two IP addresses and netmasks,
then you can use Telnet to
connect to the EM-1240-LX’s
console.
Default IP Address Default Netmask
LAN 1
192.168.3.127 255.255.255.0
LAN 2
192.168.4.127 255.255.255.0
Telnet can be used locally by using a crossover Ethernet cable to connect your computer to the
EM-1240-LX, or over a LAN or the Internet. The default IP addresses and netmasks are shown
above. To login, type the Login name and password as requested. The defaults are:
Login: root
Password: root
Once you open the “msh command shell” you can proceed to configure the EM-1240-LX’s
network settings, as described in the next section.
ATTENTION
y Serial Console Reminder: Remember to choose VT100 as the terminal type. Use the
CBL-RJ45F9-150 cable that comes with the EM-1240-LX to connect to the serial console
port. If you are not able to conect on the first try, unplug and then re-plug the EM-1240-LX’s
power cord.
y Telnet Reminder: When connecting to the EM-1240-LX over a LAN, you must configure
your PC’s Ethernet card to be on the same subnet as the EM-1240-LX you wish to contact.
2-3
