V2616A Linux Software Configuration
2-3
If a user must log in to the root account, it is advised to first take the computer offline, and then use the
command sudo –i, as below:.
moxa@Moxa:~# sudo –i
[sudo] password for moxa:
root@Moxa:~$
ATTENTION
To
enable sudo on your computer, you must fisrt add a user to the sudo group. To
add a user to the sudo group,
use the
useradd command, as below:
useradd [USER-ACCOUNT-NAME-HERE] sudo
Using the
sudoers file, sudo may be carefully tailored on a user-by-
user basis to allow a specific hierarchy of
privileges that can be tailored to individual computers within the network. For more information on
configuration, usage, and best practices with the sudo comman
d, you may refer to the following websites:
Linux.com
’s introduction to sudo:
http://www.linux.com/learn/tutorials/306766:linux-101-introduction-to-sudo
Debian
introduction to the sudo command:
https://wiki.debian.org/sudo
Ubuntu
(a Debian sub-distribution) documentation for the sudoers file:
https://help.ubuntu.com/community/Sudoers
A sample sudoers file for an extended network:
http://www.sudo.ws/sudo/sample.sudoers
Starting from a VGA Console
Connect the display monitor to the V2616A-LX VGA connector, and then power it up by connecting it to the
power adaptor. It takes approximately 30 to 60 seconds for the system to boot up. Once the system is ready,
a login screen will appear on your monitor.
To log in, type the login name and password as requested. The default values are both root.
Login: root
Password: root
Moxa login: root
Password:
Last login: Thu Sep 15 22:46:00 CST 2011 on tty1
Linux Moxa 2.6.32-5-amd64 #1 SMP Tue Jun 14 09:42:28 UTC 2011 x86_64
The programs included with the Debian GNU/Liux system are free software;
The exact distribution terms for each program are described in the
Individual files in /usr/share/doc/*/copyright.
Debian GNU/Linux comes with ABSOLUTELY NO WARRANTY, to the extent
Permitted by applicable law.
root@Moxa:~#
Connecting from a Telnet Console
The V2616A-LX computers come with two Gigabit ports named LAN1 and LAN2. The default IP addresses and
netmasks of the network interfaces are as follows:
Default IP Address Netmask
LAN 1 192.168.3.127 255.255.255.0
LAN 2 192.168.4.127 255.255.255.0
Before using the Telnet client, you should change the IP address of your development workstation so that the
network ports are on the same subnet as the IP address for the LAN port that you will connect to. For example,
