V2616A Linux Software Configuration
2-4
if you will connect to LAN1, you could set your PC’s IP address to 192.168.3.126, and the netmask to
255.255.255.0. If you will connect to LAN2, you could set your PC’s IP address to 192.168.4.126, and the
netmask to 255.255.255.0.
Use a cross-over Ethernet cable to connect your development workstation directly to the target computer, or
use a straight-through Ethernet cable to connect the computer to a LAN hub or switch. Next, use a Telnet client
on your development workstation to connect to the target computer. After a connection has been established,
type the login name and password as requested to log on to the computer. The default values are both root.
Login: root
Password: root
Connecting from an SSH Console
The V2616A-LX computers support an SSH console to offer users better network security than the Telnet.
Windows Users
Click on the link http://www.chiark.greenend.org.uk/~sgtatham/putty/download.html to download PuTTY
(free software) to set up an SSH console for the V2616A-LX in a Windows environment. The following screen
shows an example of the configuration that is required.
