3
3. Managing Communications
The V2616A-LX ready-to-run embedded computer is a network-centric platform designed to serve as a
front-end for data acquisition and industrial control applications. This chapter describes how to configure the
various communication functions supported by the Linux operating system.
The following topics are covered in this chapter:
Detecting Network Interfaces
Changing the Network Settings
Changing the “interfaces” Configuration File
Adjusting IP Addresses with “ifconfig”
Telnet/TFTP Server
Enabling the Telnet/TFTP Server
Disabling the Telnet/TFTP Server
DNS Client
/etc/hostname
/etc/resolv.conf
/etc/nsswitch.conf
Configuring Ethernet Bonding
Apache Web Server
Default Homepage
Disabling the CGI Function
Saving Web Pages to a USB Storage Device
IPTABLES
IPTABLES Hierarchy
IPTABLES Modules
Observe and Erase Chain Rules
Define Policy for Chain Rules
Append or Delete Rules
NAT (Network Address Translation)
NAT Example
Enabling NAT at Bootup
PPP (Point to Point Protocol)
Connecting to a PPP Server over a Simple
Dial-up Connection
Connecting to a PPP Server over a Hard-
wired
Link
Checking the Connection
Setting up a Machine for Incoming PPP
Connections
Routed IP the mini-PCIE module
PPPoE
NFS (Network File System) Client
SNMP (Simple Network Management
Protocol)
OpenVPN
Ethernet Bridging for Private Networks on
Different Subnets
Ethernet Bridging for Private Networks on the
Same Subnet
Routed IP
