V2616A Linux Software Components
A-16
python-central 0.6.16+nmu1 register and build utility for Python packages
python-chardet 2.0.1-1 universal character encoding detector
python-dbus 0.83.1-1 simple interprocess messaging system (Python
interface)
python-debian 0.1.18 Python modules to work with Debian-related data
formats
python-gconf 2.28.1-1 Python bindings for the GConf configuration database
system
python-glade2 2.17.0-4 GTK+ bindings: Glade support
python-gmenu 2.30.3-1 an implementation of the freedesktop menu
specification for GNOME
python-gnome2 2.28.1-1 Python bindings for the GNOME desktop environment
python-gnomeapplet 2.30.0-4 Python bindings for the GNOME panel applet library
python-gnomedesktop 2.30.0-4 Python bindings for the GNOME desktop library
python-gnomekeyring 2.30.0-4 Python bindings for the GNOME keyring library
python-gnupginterface 0.3.2-9.1 Python interface to GnuPG (GPG)
python-gobject 2.21.4+is.2.21.3-1 Python bindings for the GObject library
python-gtk2 2.17.0-4 Python bindings for the GTK+ widget set
python-minimal 2.6.6-3+squeeze6 minimal subset of the Python language (default
version)
python-numpy 1:1.4.1-5 Numerical Python adds a fast array facility to the
Python language
python-pyorbit 2.24.0-6 A Python language binding for the ORBit2 CORBA
implementation
python-software-proper
ties
0.60.debian-3 manage the repositories that you install software from
python-support 1.0.10 automated rebuilding support for Python modules
python-wnck 2.30.0-4 Python bindings for the WNCK library
python-xapian 1.2.3-3 Xapian search engine interface for Python
python2.6 2.6.6-8+b1 An interactive high-level object-oriented language
(version 2.6)
python2.6-minimal 2.6.6-8+b1 A minimal subset of the Python language (version 2.6)
python3.1 3.1.3-1 An interactive high-level object-oriented language
(version 3.1)
python3.1-minimal 3.1.3-1 A minimal subset of the Python language (version 3.1)
radeontool 1.6.1-1 utility to control ATI Radeon backlight functions on
laptops
rarian-compat 0.8.1-5 Documentation meta-data library (compatibility tools)
readline-common 6.1-3 GNU readline and history libraries, common files
rpm-common 4.8.1-6 common files for RPM
rpm2cpio 4.8.1-6 tool to convert RPM package to CPIO archive
rsyslog 4.6.4-2 enhanced multi-threaded syslogd
sed 4.2.1-7 The GNU sed stream editor
sensible-utils 0.0.4 Utilities for sensible alternative selection
sgml-base 1.26+nmu1 SGML infrastructure and SGML catalog file support
sgml-data 2.0.4 common SGML and XML data
shared-mime-info 0.71-4 FreeDesktop.org shared MIME database and spec
snmp 5.4.3~dfsg-2 SNMP (Simple Network Management Protocol)
applications
snmpd 5.4.3~dfsg-2 SNMP (Simple Network Management Protocol) agents
software-properties-gtk 0.60.debian-3 manage the repositories that you install software from
ssh 1:5.5p1-6 secure shell client and server (metapackage)
ssl-cert 1.0.28 simple debconf wrapper for OpenSSL
