V2616A Linux Managing Communications
3-21
Unpacking moxa-snmp-V2616A (from .../moxa/moxa-snmp-V2616A-1.0.deb) ...
Setting up moxa-snmp-V2616A (1.0) ...
update-rc.d: using dependency based boot sequencing
insserv: warning: script 'moxa_snmpd' missing LSB tags and overrides
Starting Moxa SNMP...
(standard_in) 2: syntax error
Starting Moxa SNMP OK
moxa@Moxa:~$
Then you can check if the snmpd is running.
moxa@Moxa:~# ps -ef
…
root 18140 1 1 10:23 pts/2 00:00:00 /bin/bash /etc/mxAgent/scripts/s
root 18147 1 0 10:23 ? 00:00:00 /bin/mxAgent -c /etc/mxAgent/mxA
root 18155 1 0 10:23 ? 00:00:00 /sbin/snmpd -Lf /var/log/snmpd.l
…
moxa@Moxa:~$
The following example shows an SNMP agent responding to a query from the SNMP browser on the host site:
SNMPv2-MIB::sysDescr.0 = STRING: Linux Moxa 3.2.0-4-amd64 #1 SMP Debian 3.2.46-1
x86_64
SNMPv2-MIB::sysObjectID.0 = OID: SNMPv2-SMI::enterprises.8691.12.2616
DISMAN-EVENT-MIB::sysUpTimeInstance = Timeticks: (11383) 0:01:53.83
SNMPv2-MIB::sysContact.0 = STRING: \"Moxa Inc., Embedded Computing Business.\"
SNMPv2-MIB::sysName.0 = STRING: Moxa
SNMPv2-MIB::sysLocation.0 = STRING: \"6F., No. 135, Ln. 235, Baoquao Rd., Xindia
n Dist., New Taipei City 231, Taiwan (R.O.C.)\"
SNMPv2-MIB::sysORLastChange.0 = Timeticks: (0) 0:00:00.00
SNMPv2-MIB::sysORID.1 = OID: SNMP-NOTIFICATION-MIB::snmpNotifyFullCompliance
SNMPv2-MIB::sysORID.2 = OID: SNMPv2-MIB::snmpMIB
SNMPv2-MIB::sysORID.3 = OID: SNMP-VIEW-BASED-ACM-MIB::vacmBasicGroup
SNMPv2-MIB::sysORID.4 = OID: SNMP-MPD-MIB::snmpMPDCompliance
SNMPv2-MIB::sysORID.5 = OID: SNMP-USER-BASED-SM-MIB::usmMIBCompliance
SNMPv2-MIB::sysORID.6 = OID: SNMP-FRAMEWORK-MIB::snmpFrameworkMIBCompliance
SNMPv2-MIB::sysORDescr.1 = STRING: The MIB modules for managing SNMP Notificatio
n, plus filtering.
SNMPv2-MIB::sysORDescr.2 = STRING: The MIB module for SNMPv2 entities
SNMPv2-MIB::sysORDescr.3 = STRING: View-based Access Control Model for SNMP.
SNMPv2-MIB::sysORDescr.4 = STRING: The MIB for Message Processing and Dispatchin
g.
SNMPv2-MIB::sysORDescr.5 = STRING: The management information definitions for th
e SNMP User-based Security Model.
…
To remove the moxa-snmp-V2616A package, use the following command.
moxa@Moxa:~$ sudo dpkg -r moxa-snmp-V2616A
(Reading database ... 31739 files and directories currently installed.)
Removing moxa-snmp-V2616A ...
Stopping Moxa SNMP ...
Stopping Moxa SNMP OK
update-rc.d: using dependency based boot sequencing
moxa@Moxa:~$
