V2616A Linux Software Configuration
2-7
Enabling and Disabling Daemons
The following daemons are already enabled when the V2616A-LX boots up for the first time.
Snmpd: SNMP Agent Daemon
Telnetd: Telnet Server/Client Daemon
Inetd: Internet Daemons
Ftpd: FTP Server/Client Daemon
Sshd: Secure Shell Server Daemon
Httpd: Apache WWW Server Daemon
Type the command
root@Moxa:~#ps –ef to list all processes currently running.
Moxa:~# ps -ef
UID PID PPID C STIME TTY TIME CMD
root 1 0 0 00:02 ? 00:00:00 init [2]
root 2 0 0 00:02 ? 00:00:00 [kthreadd]
root 3 2 0 00:02 ? 00:00:00 [migration/0]
root 4 2 0 00:02 ? 00:00:00 [ksoftirqd/0]
root 5 2 0 00:02 ? 00:00:00 [watchdog/0]
root 6 2 0 00:02 ? 00:00:00 [migration/1]
root 7 2 0 00:02 ? 00:00:00 [ksoftirqd/1]
root 8 2 0 00:02 ? 00:00:00 [watchdog/1]
root 9 2 0 00:02 ? 00:00:00 [events/0]
root 10 2 0 00:02 ? 00:00:00 [events/1]
root 11 2 0 00:02 ? 00:00:00 [cpuset]
root 12 2 0 00:02 ? 00:00:00 [khelper]
root 13 2 0 00:02 ? 00:00:00 [netns]
root 14 2 0 00:02 ? 00:00:00 [async/mgr]
root 15 2 0 00:02 ? 00:00:00 [pm]
root 17 2 0 00:02 ? 00:00:00 [sync_supers]
root 18 2 0 00:02 ? 00:00:00 [bdi-default]
root 19 2 0 00:02 ? 00:00:00 [kintegrityd/0]
root 20 2 0 00:02 ? 00:00:00 [kintegrityd/1]
root 21 2 0 00:02 ? 00:00:00 [kblockd/0]
root 22 2 0 00:02 ? 00:00:00 [kblockd/1]
root 23 2 0 00:02 ? 00:00:00 [kacpid]
root 24 2 0 00:02 ? 00:00:00 [kacpi_notify]
root 25 2 0 00:02 ? 00:00:00 [kacpi_hotplug]
root 26 2 0 00:02 ? 00:00:00 [ata/0]
root 27 2 0 00:02 ? 00:00:00 [ata/1]
www-data 2707 2664 0 00:03 ? 00:00:00 /usr/sbin/apache2 -k start
www-data 2708 2664 0 00:03 ? 00:00:00 /usr/sbin/apache2 -k start
www-data 2709 2664 0 00:03 ? 00:00:00 /usr/sbin/apache2 -k start
www-data 2710 2664 0 00:03 ? 00:00:00 /usr/sbin/apache2 -k start
root 2720 2700 0 00:15 tty1 00:00:00 -bash
root 2724 2 0 00:15 ? 00:00:00 [flush-8:0]
root 2745 2536 1 00:21 ? 00:00:00 sshd: root@pts/0
root 2747 2745 0 00:21 pts/0 00:00:00 -bash
root 2751 2747 0 00:21 pts/0 00:00:00 ps -ef
Moxa:~#
