MPC-2240 Hardware Manual UART Commands for Display Control
B-6
Example：
Switch to DUSK mode
0x07 0xFF 0x45 0x4D 0x53 0x01 0x13 0x01 0xFE
ACK
0x06 0xFF 0x45 0x4D 0x53 0x01 0x14 0x01 0xFE
NACK
0x15 0xFF 0x45 0x4D 0x53 0x01 0x0B 0x01 0xFE
