MD-124 HW Manual On-screen Display and Display Configuration

OSD Menu Items Explained

The following section explains all possible image properties that the user can encounter or adjust. The menu location of

each item is described as a filetree path. Please review the OSD Menu Map earlier in this manual for an overview of the

menu file structure. Most parameters may be adjusted in real time, so you do not need to exit the OSD menu to check

Electronically increase/decrease the overall brightness of the panel by adjusting the voltage level.

This applies to the Main Source signal. Window overlays (PIP/PBP) and the OSD Menu overlay will be

This is only available in Full Menu mode.

This increases/decreases the overall contrast of the panel electronically by controlling the voltage level.

This applies to the Main Source signal. Window overlays (PIP/PBP) and the OSD Menu overlay will be

This only applies to analog VGA/RGB signals.

This adjusts the horizontal frequency of the analog signal to improve visibility of the entire image. When it is

adjusted, you will notice that the image will appear to be stretched and might in some situations start to flicker/

scroll, at which point you must reverse the last adjustment to stop it from flickering/scrolling anymore. This function

can be used for older signals that are not automatically detected by the internal display controller.

This increases/decreases the overall image sharpness. This affects the whole panel, and applies to all signal inputs

and window overlays (PIP/PBP). Use it to increase the visual quality of signals from possible older equipment or

electronically weak signals.
