MD-124 HW Manual On-screen Display and Display Configuration

B-9

Display-Picture-PIP/PBP Adjust-PIP Picture-Contrast

To enable this function, please see Display-Source-PIP-xxxx, below.

This increases/decreases the overall contrast of the window overlay. This will not change the contrast of the Main

Source signal behind the window overlay. It can be used for situations where the incoming video signal from CCTV

or other video sources appears washed out in comparison to the source signal.

Scale is from 0-100. 50 is the default.

Display-Picture-PIP/PBP Adjust-PIP Picture-Sharpness

To enable this function, please see Display-Source-PIP-xxxx, below.

This increases/decreases the overall image sharpness. This will not change the sharpness of the Main Source signal

behind the window overlay. Use it to increase the visual quality of signals from possible older equipment or

electronically weak signals.

Scale is from 0-15 steps. 7 is default.

Display-Picture-PIP/PBP Adjust-PIP Picture-Color

This only applies to analog VIDEO IN signals.

To enable this function, please see Display-Source-PIP-xxxx, below.

This increases/decreases the overall color saturation for video signals. Can be used if the incoming signal lacks

strong colors because it originates in older equipment, or is transmitted over bad cables. This will not change the

color saturation/intensity of the Main Source signal behind the window overlay. Note that this function can also

make noisy color signals appear crisper/clearer if the parameter is reduced towards the grayscale.

Scale is from 0-100. 50 is the default.

Display-Picture-PIP/PBP Adjust-PIP Picture-Tint

This only applies to analog VIDEO IN signals.

To enable this function, please see please see Display-Source-PIP-xxxx, below.

This increases/decreases the overall video tint (applies only for NTSC video signals.), making all colors brighter or

darker. This may make the image appear washed out or stronger in terms of color intensity. Can be used if the

incoming signal from older equipment or bad cables lacks strong colors. This will not change the color tint of the

Main Source signal behind the window overlay.

Scale is from 0-100. 50 is the default.

Picture: Advanced Settings

Display-Picture-Adv Settings-Color Temperature- xx00K

This adjusts the overall color temperature, as measured in Kelvin degrees. You can choose between 9300K and

6500K. This applies to the Main Source signal. Window overlays (PIP/PBP) and the OSD Menu overlay will be

unaffacted. Lower values make the image appear warmer, while higher values will make it appear cooler. Default is

set to 6500K. Please refer to the Kelvin color temperature scale below (approximate and symbolic):

When selected, a box icon (█) will indicate that the selected function has been activated.
